Product Features
■ Contains a premium grade speaker unit
■ Best reliability
■ Easy installing and convenience
■ Full Range of 1 way speaker system (6.5″unit)
CS-606F
Ceiling SpeakersDownload
-
Manual
-
Brochure
Product specification
| CS-606F | ||
|---|---|---|
| Unit | 6.5″ | |
| Power Handling (AES) | 6W | |
| Input Power | 100V | 6W/3W/1W |
| 70V | - | |
| Impedance | 100V | 1.66kΩ(6W)/3.3kΩ(3W)/10kΩ(1W) |
| 70V | - | |
| LOW | - | |
| Frequency Range (-20%) | 88Hz ~ 17.4kHz | |
| Sensitivity (1W/1m) | 85dB | |
| Maximum SPL | 93dB | |
| Nominal Dispersion (HxV) | 1kHz | 180° |
| 4kHz | 60° | |
| Weight (Net) | 0.63kg | |
| Dimensions (Net, WxHxD) | 230(ø) x 100(D)mm | |
