■ INTEGRATED SYSTEM

    System consists of EMERGENCY SWITCHER, MATRIX, RELAY GROUP, SPEAKER SELECTOR, and TERMINAL BOARD functions.

■ BROADCAST CONTROL DEPENDING ON PRIORITIES

    It controls the priority broadcasting by connecting to emergency panel (EP-6216) and remote MIC (RM-6024).

    It switches to remote or emergency broadcasting due to priorities of emergency signals or outside remote signals (remote MIC broadcasting signals) even if during general broadcasting.

■ AUTOMATIC FIRE DETECTING FUNCTION

    With 16-channels corresponding to fire contact point signals, fire alarm broadcasting will be transmitted automatically.

■ MANUAL CONTROL OF EMERGENCY AND GENERAL BROADCASTS

    It can broadcast to desired channels by manually selecting emergency or general broadcasting.

■ DISPLAY BROADCASTING STATUS

    It displays the priority and broadcasting status on LED, so user can verify the broadcasting status without any effort.

■ MEMORY/SAVE FUNCTION

    Fire/RM Macro information will be saved in internal PC memory allowing for normal operation in event of PC error.

■ CHANNEL EXPANSION AND RS-485 COMMUNICATION INTERFACE

    Long distance transmission is available and system can be expanded to 160 Zones by utilizing ECS-6216S.

■ INSTALLATION TIME AND SPACE

    Since it is an integrated system, it is easy to install and can save installation labor, time and space.
