NRM-8000A

Remote Microphone

Download

  • Manual

  • Brochure

Product Features

■ Gooseneck Microphone
    Using Gooseneck microphone, you can broadcast paging to each area.
■ Broadcasting Area Set Saving Function (Preset)
    You can set and save the broadcasting area using PC. Using this function, you can select and broadcast the broadcasting area more easily.
■ All Zone, Talk, Chime button
    Using each button, simple manipulation is possible, and the operation mode of Talk button and Chime button can be set.
■ 2.43 inch OLED DISPLAY
    Through Display, you can check and set the status of device.
■ Output level meter
    You can check the output level through the level meter.
■ Monitor speaker
    Through monitor speaker, you can check the present output real time.
■ Input/ Output Control Volume
    You can control MIC Input GAIN, monitor speaker output and Chime volume.
■ DC 24V Auxiliary Power Input
    There is DC 24V auxiliary power input terminal to input auxiliary power using the adapter.

Product specification

 NRM-8000A
Audio characteristics
Input sensitivity-50dBu
Output level0dBu
Signal vs. noise ratio(20kHz LPF)60dB or more
THD(20kHz LPF)0.5% or less
Frequency response 100Hz ~ 18kHz0dBu ± 3dBu
Data communication
Communication modeCAN (Controller Area Network)
Communication velocity20kpbs
Communication distanceMAX : 300m
Common characteristics
Operation temperature-10℃ ~ +40℃
Power sourceDC 40V (300m or more Use DC 24V adapter)
Power consumptionMAX 10W
Weight (set)1.37kg/3.02lb
Dimensions (set)200(W) x 73(H) x 206(D)mm/7.9(W) x 2.9(H) x 8.1(D)in
