PA-935N

Public Address Amplifier

Download

  • Manual

Product Features

■ High Power, Low Distortion
    35W of RMS power, with less than 3% THD.
■ Versatile and Convenient
    Three mixable inputs: MIC1, MIC2/AUX, MIC3/CD/SATELLITE and TELEPHONE.
■ Configurable
    Mic 2/Aux and Mic 3/CD/Satellite are individually selectable.
■ Telephone Input
    Telephone input for connection with telephone system.
■ Priority DUCKING
    MIC2/AUX and MIC3/CD/SATELLITE inputs duck when MIC1 in use.
    Also, MIC1, MIC2/AUX and MIC3/CD/SATELLITE inputs duck when telephone in use.
■ Tone Control
    Separate Bass and Treble controls to tailor your sound.

Product specification

  PA-935N
Rated Output Power (at 1kHz, T.H.D : 3%) 35W (RMS)
Frequency Response (+1,-3dB)Mic 1, 2, 3150Hz-12kHz
Aux80Hz-15kHz
CD/Satellite80Hz-15kHz
Telephone330Hz-3kHz
T.H.D (at Rated Output -5dB, 1kHz) Less Than 1%
S/NMic 1, 2, 3Better than 60dB
Aux, CD/Satellite, TelephoneBetter than 75dB
Input Sensitivity/ImpedanceMic 1, 2, 3-50dB/600Ω
Aux-15dB/10kΩ
CD/Satellite-15dB/10kΩ
Telephone EC & Associated, JAPAN : 0.775V/600Ω,
USA / Canada & Associated : 0.3V/600Ω
Tone ControlHigh±10dB at 10kHz / Shelving
Low±10dB at 100Hz / Shelving
Output Voltage/ImpedanceEC & Associated, JAPAN 4Ω / 11.8V8Ω / 16.7V140Ω / 70V 286Ω / 100V
USA/CANADA & Associated4Ω / 11.8V8Ω / 16.7V18Ω / 25V140Ω / 70V
Operating temperature -10˚C ~ +40˚C
Power Source 100–120VAC or 220–240VAC; 50/60Hz
(Supplied AC mains transformer depends on country requirements)
Power Consumption 40W
Weight 4.4kg / 9.7lb
Dimensions 290(W) x 76(H) x 185(D)mm / 11.4(W) x 3(H) x 7.3(D)in
