Product Features

■ EASY TO OPERATE
    Distributes a single channel input to six outputs.
■ EASY LEVEL ADJUSTMENT
    Front-panel input and output level adjustment.
■ INPUT MONITORING
    Input peak LED monitoring.

Product specification

	PO-6106
Channels	1 Input, 6 Outputs
Frequency Response	20Hz-20kHz (±3dB)
THD at 1kHz, Rated Output	Less than 0.1%
Input Sensitivity	1V ±0.2V Balanced
Output Level	3V ±0.5V Balanced
S/N	Better than 70dB
Residual Noise	Less than -95dB
Operating Temperature	-10°C ~ +40°C / 14°F ~ 104°F
Power Source	100–120VAC or 220–240VAC; 50/60Hz, DC 24V (Supplied AC main transformer depends on country requirements)
Power Consumption	8W
Weight (SET)	4kg/8.8lb
Dimensions (SET)	482(W)x44(H)x280(D)mm/19(W)x1.7(H)x11(D)in
