■ Memory of 40 FM/AM frequencies
40 broadcasting frequencies can be memorized.
■ Auto Scan
Broadcast station can be selected automatically with automatic seek function.
■ AMX, CRESTRON INTERFACE
It supports the control port to integrate with the remote control device such as AMX and CRESTRON control systems for the user assignments.
| TU-6200 |
|---|---|
FM (75kHz MOD. 1kHz) | |
Tuning range | 87.5~108.0MHz |
Sensitivity | 6dB(Less than 10dB) |
T.H.D. (Mono) | 0.3% (Less than 1%) |
S/N (mono) | 60dB (Better than 50dB) |
Output level (75kHz MOD.) | 0dB±3 dB |
AM (30% MOD 400Hz) | |
Tuning range | Europe: 522~1629kHz, U.S.A: 520~1710kHz |
Sensitivity | 82dB(Less than 86dB) |
S/N | 35dB(Better than 30dB) |
THD | 1.5% (Less than 3%) |
Output level | -10dB±3 dB |
Operation Temperature | -10℃ ~ +40℃ |
Power source | 100–120VAC or 220–240VAC; 50/60Hz (Supplied AC mains transformer depends on country requirements) |
Power consumption | 7W |
Weight (SET) | 4.2kg/9.3lb |
Dimensions (SET) | 482(W)×88(H)×280(D)mm/19(W)x3.5(H)x11(D)in |
